Industrial Automation Products

ALLEN BRADLEY • RKD3373280

836-C5
836 PRESSURE CONTROLS
DEVICE STYLE C
24-600VAC AT 125 VA/125-250VDC AT 57.5 VA
RANGE 0-80PSI/0-5.5BAR
MAX PRESSURE 190PSI/13.1 BAR
EXTERNAL COPPER ALLOY BELLOWS
NO ENCLOSURE
NO MODIFICATIONS

ALLEN BRADLEY • RKD3373277

836-C2E
PRESSURE CONTROLS - GENERAL INDUSTRIAL
DEVICE STYLE C
EXTERNAL COPPER ALLOY BELLOWS
TYPE 7 &
9 AND 4 &
13 COMBINED METALLIC ALUMINUM ENCLOSURE
NO MODIFICATIONS

ALLEN BRADLEY • RKD3373272

836-AV11-JKC7
PRESSURE SWITCH

ALLEN BRADLEY • RKD3373172

803-PL4
LIMIT SWITCH ROTATING CAM 0-400RPM 25AMP 600VAC

ALLEN BRADLEY • RKD3373170

802X-WS17
LIMIT SWITCH
NEMA TYPE 4 AND 13 OILTIGHT CONSTRUCTION
CAT WHISKER
NEMA TYPE 7 AND 9

ALLEN BRADLEY • RKD3373168

802X-CM7
LIMIT SWITCH
NEMA TYPE 4 AND 13
OILTIGHT CONSTRUCTION
SIDE PUSH ROD
AC MAX 10 AMP MAX
MAINTAINED CONTACT

ALLEN BRADLEY • RKD3373152

802T-NX189
LIMIT SWITCH
FULL SWITCH ASSEMBLY
METAL BODY
ROTARY LEVER ARM

ALLEN BRADLEY • RKD3373155

802T-NX50
LEVER ARM
OPERATING LEVER
FOR CUSTOM NEMA LIMIT SWITCH
ROD LEVER
STAINLESS STEEL ROD
12 IN LONG
0.13 IN
MOUNTABLE

ALLEN BRADLEY • RKD3373148

802T-NPJ1
STANDARD LIMIT SWITCH
FULL SW HEAD &
BODY
STANDARD NON-PLUG-IN
2 CIRCUITS
ROTARY LEVER ARM
CLOCKWISE &
COUNTERCLOCKWISE
STANDARD MOUNTING
428

ALLEN BRADLEY • RKD3373164

802T-WS1P
LIMIT SWITCH
NEMA TYPE 4 AND 13
OILTIGHT CONSTRUCTION
PLUG-IN
WOBBLE STICK
WIRE
2-CIRCUIT
WHOLE SWITCH

ALLEN BRADLEY • RKD3373159

802T-NX59
LIMIT SWITCH
OPERATING LEVER
GOLD CONTACTS
STAINLESS STEEL ROD

ALLEN BRADLEY • RKD3373161

802T-R4TD
LIMIT SWITCH
STANDARD
FULL SW HEAD &
BODY
NON-PLUG-IN TIME DELAY
2 CIRCUITS
ROTARY LEVER ARM
COUNTERCLOCKWISE ONLY
STANDARD MOUNTING
467

ALLEN BRADLEY • RKD3373166

802T-WSP
PLUG-IN OILTIGHT LIMIT SWITCH
METAL
10 A
WOBBLE STICK
2 CIRCUITS
CONDUIT ENTRY
STANDARD CONTACTS
1 NO
1 NC
STANDARD LOW TEMPRATURE
SNAP ACTING
1/2 INCH NPT THREAD
PUSH ACCUATION
SPRING RETURN
FULL SWITCH (HEAD &
BODY)
NOT DIRECT ACTING

ALLEN BRADLEY • RKD3373102

802T-AT
LIMIT SWITCH
NEMA TYPE 4/13
OILTIGHT CONSTRUCTION
NON-PLUG-IN
LEVER TYPE
SPRING RETURN
STANDARD OPERATING TORQUE
4-CIRCUIT
CW AND CCW OPERATION
600 VAC MAX
10 AMP MAX

ALLEN BRADLEY • RKD3373144

802T-KP
LIMIT SWITCH
PLUG-IN STYLE
WITHOUT LEVER
OPERATOR TYPE - SIDE PUSH ROLLER
VERTICAL
2 CIRCUIT
NEMA TYPE 4/13
OILTIGHT
MOUNTABLE

ALLEN BRADLEY • RKD3373150

802T-NX119
OPERATING LEVER
ROD LEVER
NYLATRON LOOPED ROD
9 IN LONG
2 IN WIDE LOOP
0.18 IN

ALLEN BRADLEY • RKD3373140

802T-K1TP
LIMIT SWITCH
PLUG-IN
OILTIGHT
METAL
10 A STANDARD ENERGY
HORIZONTAL SIDE PUSH ROLLER
4 CIRCUITS
CONDUIT ENTRY
STANDARD CONTACTS
2 NORMALLY OPEN CONTACTS
2 NORMALLY CLOSED CONTACTS
STANDARD LOW TEMPRATURE
SNAP ACTING
1/2"
NPT THREAD

ALLEN BRADLEY • RKD3373146

802T-NP
LIMIT SWITCH
10/60 AMP
600 VAC MAX
NON PLUG-IN
LEVER TYPE
SPRING RETURN
NEUTRAL POSITION
2 CIRCUIT
CW AND CCW OPERATION
WHOLE SWITCH
NEMA TYPE 4 AND 13 OIL-TIGHT CONSTRUCTION
MOUNTABLE

ALLEN BRADLEY • RKD3373142

802T-K1TP1
LIMIT SWITCH
PLUG-IN OILTIGHT
METAL
10 A STANDARD ENERGY
HORIZONTAL SIDE PUSH ROLLER
4 CIRCUITS
STANDARD CONTACTS
2 NORMALLY OPEN CONTACTS
2 NORMALLY CLOSED CONTACTS
STANDARD LOW TEMPRATURE

ALLEN BRADLEY • RKD3373136

802T-HW1
STANDARD LIMIT SWITCH
FULL SW HEAD &
BODY
STANDARD NON-PLUG-IN
2 CIRCUITS
ROTARY LEVER ARM
CLOCKWISE &
COUNTERCLOCKWISE
STANDARD MOUNTING
0.27"

1.5"

CAST ROLL

ALLEN BRADLEY • RKD3373128

802T-FP1
LIMIT SWITCH
NEMA TYPE 4 AND 13 OILTIGHT CONSTRUCTION
PLUG-IN
LEVER TYPE
SPRING RETURN
STANDARD OPERATING TORQUE
NOMINAL TRAVEL
2-CIRCUIT
CW A

ALLEN BRADLEY • RKD3373132

802T-HP1
LIMIT SWITCH
NEMA TYPE 4 AND 13 OILTIGHT CONSTRUCTION
PLUG-IN
LEVER TYPE
SPRING RETURN
HIGH OPERATING TORQUE
2-CIRCUIT
CW AND CCW OPERATION
HE

ALLEN BRADLEY • RKD3373130

802T-H1TW2
DISCONTINUED BY MANUFACTURER
LIMIT SWITCH
OILTIGHT
WITH HEAD
MOUNTABLE
600 VAC
1.2-6 AMP

ALLEN BRADLEY • RKD3373138

802T-K1-COVER
LIMIT SWITCH COVER
DATA PLATE
802T SERIES
METAL
SCREW COVER
MOUNTABLE
