Industrial Automation Products

SMC • RKD3256899

ZX1051-K15H-E
VACUUM
EJECTOR SYSTEM
0.5 MM EJECTOR UNIT NOZZLE DIAMETER
WITH SILENCER EJECTOR EXHAUST

SMC • RKD3256876

ZSE40A-N01-V-P
DIGITAL PRESSURE SWITCH
SERIES ZSE40A(F)
2-COLOR DISPLAY HIGH PRECISION
0 TO -14.69 PSI
NPT 1/8IN W/ M5 FEMALE THREAD
PNP OPEN COLLECTOR 2 OUTPUTS + ANALOG CURRENT/AUTO-SHIFT SWITCHING
W/ UNIT SWITCHING FUNCTIONS - INITIAL PSI VALUE

SMC • RKD3256779

ZR100-K15MZ-F
"
SMC EXTERNAL VACUUM
K1
CONNECTOR"

LARGE SIZE VACUUM MODULE

SMC • RKD3256776

ZQ1101U-J13L-EBG-00
SPACE SAVING VACUUM EJECTOR
W/ SILENCER FOR SINGLE UNIT
N.C.-SUPPLY
STANDARD (DC:1W)
110 VAC
L-TYPE CONNECTOR W/ .3M LEAD WIRE
0 TO -101 PNP 2 OUTPUTS W/ SUCTION FILTER
W/ UNIT SWITCHING FUNCTION
LEAD WIRE W/ CONNECTOR(LEAD WIRE LENGTH 2M W/ CONNE

CHERNE INDUSTRIES • RKD3256763

273-318
MECHANICAL PLUG ECONO-GRIP 1-1/2-38MM

SMC • RKD3256773

ZQ1071RU-K15L-EBG-00-X133-Q
SPACE SAVING VACUUM EJECTOR
.7MM NOZZLE
W/ SILENCER FOR SINGLE UNIT
N.C.-SUPPLY + N.C.-RELEASE
STANDARD (DC:1W)
24 VDC
L-TYPE CONNECTOR W/ .3M LEAD WIRE
0 TO -101 PNP 2 OUTPUTS W/ SUCTION FILTER
W/ UNIT SWITCHING FUNCTION
MADE TO ORDER

SMC • RKD3256698

ZM133M-Q5-E14
VACUUM EJECTOR
1.3MM NOZZLE DIAMETER
MANIFOLD: W/ COMMON SUP VALVE
SIDE/BOTTOM ENTRY
.35 MPA
RC
SUPPLY + RELEASE VALVE - M5X0.8
DC: 1 W (W/ INDICATOR LIGHT: 1.05 W)
AIR OPERATED/ W/O VALVE
W/O SUPPRESSOR
NON-LOCKING (PUSH)
1 OUTPUT - 3 ROTATION

SMC • RKD3256704

ZMA103H-K5-T14C
DISCONTINUED BY MANUFACTURER
VACUUM EJECTOR
W/ SOLID STATE TIMER
1MM
COMMON SUP FOR MANIFOLD
.5 MPA
RC
W/ AIR SUPPLY VALVE
VACUUM RELEASE VALVE
24 VDC
1 POINT
3 TURNS
NPN OUTPUT
.6M LEAD WIRE
W/O LOCK NUT

CHERNE INDUSTRIES • RKD3256719

271-535
DISCONTINUED BY MANUFACTURER
MECHANICAL PIPE PLUG
3IN
2 PSI

SMC • RKD3256681

ZM131HT-K3LZ-E55L
VACUUM EJECTOR
1.3MM NOZZLE DIAMETER
SINGLE UNIT: W/ VALVE + STANDARD SILENCER
SIDE/BOTTOM ENTRY
.5 MPA
NPTF
SUPPLY (NC) &
RELEASE VALVE
DC: 1 W (W/ INDICATOR LIGHT: 1.05 W)
110 VAC
L PLUG CONNECTOR
.3M LEAD WIRE
W/ LIGHT/SURGE SUPPRESSOR

SMC • RKD3256663

ZL6HN04P-K15LZ-G
MULTISTAGE EJECTOR
600L/MIN(ANR)
.50MPA
2XNPT1/2 5/16IN
PORT EXHAUST
SUPPLY NC
RELEASE NC
24 VDC
L PLUG
.3M LEAD WIRE
LIGHT/SURGE SUPPRESSOR
NON-LOCKING PUSH
PRESSURE GAUGE

SMC • RKD3256701

ZM151S-K5HZB-L
VACUUM EJECTOR
1.5MM NOZZLE DIAMETER
SINGLE UNIT: W/ VALVE + STANDARD SILENCER
SIDE/BOTTOM ENTRY
.45 MPA
RC
SUPPLY (NC) &
RELEASE VALVE
DC: 1 W (W/ INDICATOR LIGHT: 1.05 W)
24 VDC
GROMMET
.6M LEAD WIRE
W/ LIGHT/SURGE SUPPRESSOR
W/O SWITCH

SMC • RKD3256695

ZM133M-Q5
VACUUM EJECTOR
1.3MM NOZZLE DIAMETER
MANIFOLD: W/ COMMON SUP VALVE
SIDE/BOTTOM ENTRY
.35 MPA
RC
SUPPLY + RELEASE VALVE - M5X0.8
DC: 1 W (W/ INDICATOR LIGHT: 1.05 W)
AIR OPERATED/ W/O VALVE
W/O SUPPRESSOR
NON-LOCKING (PUSH)
W/O SWITCH

SMC • RKD3256655

ZL212-G
MULTISTAGE EJECTOR
BUILT-IN SILENCER
VACUUM PRESSURE GAUGE

SMC • RKD3256687

ZM132H-E15L
VACUUM EJECTOR
1.3MM NOZZLE DIAMETER
SINGLE UNIT: W/ STANDARD SILENCER W/O VALVE
SIDE/BOTTOM ENTRY
.5 MPA
RC
W/O VALVE
AIR OPERATED/ W/O VALVE
W/O SUPPRESSOR
1 OUTPUT - 200
GROMMET
3M LEAD WIRE

SMC • RKD3256653

ZL112-SP01
DISCONTINUED BY MANUFACTURER
FILTER ELEMENT KIT
FOR MULTI STAGE VAC EJECTOR
REPLACEMENT KIT

SMC • RKD3256690

ZM133H-B5LZ-E15
VACUUM EJECTOR
1.3MM NOZZLE DIAMETER
MANIFOLD: W/ COMMON SUP VALVE
SIDE/BOTTOM ENTRY
.5 MPA
RC
SUPPLY (NO) &
RELEASE VALVE
DC: 1 W (W/ INDICATOR LIGHT: 1.05 W)
24 VDC
L PLUG CONNECTOR
.3M LEAD WIRE
W/ LIGHT/SURGE SUPPRESSOR
NON-LOCKING (PUSH)

CHERNE INDUSTRIES • RKD3256631

260-118
DISCONTINUED BY MANUFACTURER
10INCH MUNI-BALL W/ REMOVABLE 2INCH PLUG
MAXIMUM INFLATION 35 PSIG

SMC • RKD3256615

ZK2-FE1-3-A
FILTER ELEMENT
ZK SERIES FILTER
SOLD IN PACK QTY OF 10

SMC • RKD3256675

ZM103HT-K5LZ-M21L
VACUUM EJECTOR
1MM NOZZLE DIAMETER
MANIFOLD: W/ COMMON SUP VALVE
SIDE/BOTTOM ENTRY
.5 MPA
NPTF
SUPPLY (NC) &
RELEASE VALVE
DC: 1 W (W/ INDICATOR LIGHT: 1.05 W)
24 VDC
L PLUG CONNECTOR
.3M LEAD WIRE
W/ LIGHT/SURGE SUPPRESSOR
NON-LOCKING (PUSH)

SMC • RKD3256669

ZM073HF-K5LOZ-E55CL-Q
VACUUM EJECTORVACUUM EJECTOR
0.7MM NOZZLE DIAMETER
MANIFOLD: W/ COMMON SUP VALVE
SIDE/BOTTOM ENTRY
.5 MPA
G
SUPPLY (NC) &
RELEASE VALVE
DC: 1 W (W/ INDICATOR LIGHT: 1.05 W)
24 VDC
L PLUG W/O CONNECTOR
W/ LIGHT/SURGE
W/O LOCK NUT
CE COMPLIANT

SMC • RKD3256678

ZM104M-E15L
DISCONTINUED BY MANUFACTURER
VACUUM EJECTOR
1MM NOZZLE DIAMETER
MANIFOLD: W/O COMMON SUP VALVE
SIDE/BOTTOM ENTRY
.35 MPA
RC
W/O VALVE
AIR OPERATED/ W/O VALVE
W/O SUPPRESSOR
1 OUTPUT - 200
GROMMET
3M LEAD WIRE

SMC • RKD3256666

ZM071H-A5L
DISCONTINUED BY MANUFACTURER
VACUUM EJECTOR
0.7MM NOZZLE DIAMETER
SINGLE UNIT: W/ VALVE + STANDARD SILENCER
SIDE/BOTTOM ENTRY
.5 MPA
RC
SUPPLY VALVE (NO)
DC: 1 W (W/ INDICATOR LIGHT: 1.05 W)
24 VDC
L PLUG CONNECTOR
.3M LEAD WIRE
W/O SUPPRESSOR

SMC • RKD3256684

ZM131HT-K5LZ-E15
VACUUM EJECTOR
1.3MM NOZZLE DIAMETER
SINGLE UNIT: W/ VALVE + STANDARD SILENCER
SIDE/BOTTOM ENTRY
.5 MPA
NPTF
SUPPLY (NC) &
RELEASE VALVE
DC: 1 W (W/ INDICATOR LIGHT: 1.05 W)
24 VDC
L PLUG CONNECTOR
.3M LEAD WIRE
W/ LIGHT/SURGE SUPPRESSOR
