Industrial Automation Products

ALLEN BRADLEY • RKD3465683

1492-L3-B
TERMINAL BLOCK
SPRING CLAMP CONNECTION
FEED THROUGH
5.1 X 59.5 X 31.3MM (0.20 X 2.34 X 1.23 IN)
1 POLE
BLUE
00
VOLTAGE RATING UR - 600V AC/DC
CSA - 600V AC/DC
IEC - 800V AC/DC
ATEX - 550V AC/DC
MAXIMUM CURRENT RATING UR - 25A

ALLEN BRADLEY • RKD3465670

1492-JKD3TP
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH WITH KNIFE DISCONNECT AND TEST SCREWS
5.1 X 60 X 47MM (0.20 X 2.36 X 1.88 IN)
1POLE
GRAY0
VOLTAGE RATING UR - 300V AC/DC
CSA - 300V AC/DC
IEC - 500V AC/DC
MAXIMUM CURRENT RATING UR

ALLEN BRADLEY • RKD3465678

1492-L10-G
ONE-CIRCUIT FEED-THROUGH BLOCK
10 MM MAX. WIRE
GREEN
IEC
MOUNTABLE

ALLEN BRADLEY • RKD3465676

1492-K3T-B
SINGLE CKT. IDC TERM. BLK.
2.5MM MAX. WIRE
W/TRIPLE CLAMP BLOCK
BLUE

ALLEN BRADLEY • RKD3465674

1492-JTC3N
TERMINAL BLOCK
SCREW CONNECTION
2 CIRCUIT THERMOCOUPLE
1 CIRCUIT-NI-CR-SI
1 CIRCUIT -NI-SI-MG
10.2 X 60 X 43MM (0.40 X 2.36 X1.69 IN)
1 POLE
GRAY
55 V AC/DC
WIRE RANGE (RATED CROSS SECTION) V IEC

ALLEN BRADLEY • RKD3465672

1492-JKD4-B
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH WITH KNIFE DISCONNECT
6.1 X 60 X 39.5MM (0.24 X 2.36 X 1.56 IN)
1 POLE
BLUE
00
VOLTAGE RATING UR - 600V AC/DC
CSA - 300V AC/DC
IEC - 400V AC/DC
MAXIMUM CURRENT RATING UR - 22A
CSA - 1

ALLEN BRADLEY • RKD3465666

1492-JG4TW
TERMINAL BLOCK
SCREW CONNECTION
SINGLE LEVEL GROUNDING WITH 3 CONNECTION POINTS 2 ON ONE SIDE
6.1 X 63 X 46MM (0.24 X 2.49 X1.81 IN)
1 POLE
GREEN/YELLOW
WIRE RANGE (RATED CROSS SECTION) V UR - #30A10 AWG
CSA - #30A10 AWG
IEC - 0.

ALLEN BRADLEY • RKD3465664

1492-JG3TW
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH GROUNDING WITH 3 CONNECTION POINTS - 2 ON ONE SIDE
5.1 X 60 X 39.5MM (0.20 X 2.36 X1.56 IN)
1 POLE
GREEN/YELLOW0
WIRE RANGE (RATED CROSS SECTION) V SINGLE SIDE UR - #22A12 AWG
CSA - #22

ALLEN BRADLEY • RKD3465668

1492-JG6
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH GROUNDING
8.1 X 60 X 39.5MM (0.319 X 2.36 X 1.56 IN)
1 POLE
GREEN/YELLOW
WIRE RANGE (RATED CROSS SECTION) UR - #228 AWG
CSA - #228 AWG
IEC - 6MM
ATEX - #2010 AWG

ALLEN BRADLEY • RKD3465662

1492-JDG3PSSTP
IEC 2-CIRCUIT FEED-THROUGH GROUND BLOCK
SELECTABLE COMPONENT PLUG-IN DEVICE WITH INTERNAL SURGE SUPPRESSION AND WITH TEST PLUG SOCKET
2.5MM MAX. WIRE
GRAY

ALLEN BRADLEY • RKD3465647

1492-JD3RB222
TERMINAL BLOCK
2200 OHM RESISTANCE
1 POLE
300 VAC/VDC RU/CSA RATING
400 VAC/VDC IEC RATING
5.1 X 69 X55.5 MM (0.20 X 2.72 X 2.19 INCH) DIMENSIONS
30-12 AWG RATED WIRE RANGE

ALLEN BRADLEY • RKD3465660

1492-JDG3P
TERMINAL BLOCK
SCREW CONNECTION
TWO LEVEL PLUG-IN STYLE - TWO CIRCUIT WITH GROUND CONNECTION
5.1 X 80.2 X 65.9MM (0.20 X 3.20 X2.63 IN)
1 POLE
GRAY
VOLTAGE RATING UR - 300V AC/DC
CSA - 300V AC/DC
IEC - 500V AC/DC
MAXIMUM CURRENT

ALLEN BRADLEY • RKD3465655

1492-JDG3
TERMINAL BLOCK
SCREW CONNECTION
TWO CIRCUIT - ONE FEED THROUGH AND ONE GROUNDING CIRCUIT
5.1 X 69 X 55.5MM (0.20 X 2.72 X 2.19IN)
1 POLE
GRAY0
VOLTAGE RATING UR - 300V AC/DC
CSA - 300V AC/DC
IEC - 400V AC/DC
ATEX - 275V AC/DC

ALLEN BRADLEY • RKD3465653

1492-JD4-G
TERMINAL BLOCK
IEC TWO-LEVEL FEED-THROUGH
4 MM MAX. WIRE
600/300/800/550 V AC/DC
35/30/32/28 AMPS
GREEN

ALLEN BRADLEY • RKD3465645

1492-JD3PSS
TERMINAL BLOCK
2 CIRCUIT
SELECTABLE COMPONENT PLUG-IN DEVICE
INTERNAL SURGE SUPPRESSOR
20 AMP
300V AC/DC
GRAY
24 - 12 AWG
2.5 MM
MOUNTABLE

ALLEN BRADLEY • RKD3465649

1492-JD3RB471
IEC 2-CIRCUIT FEED-THROUGH BLOCK
TWO LEVEL BLOCK WITH A SELECTABLE RESISTOR VALUE BETWEEN THE 2 LEVELS
4MM MAX. WIRE
GRAY
470 OHM RESISTANCE

ALLEN BRADLEY • RKD3465643

1492-JC3
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH WITH 2 PLUG-IN COMB CONNECTIONS ON ONE SIDE
5.1 X 45.4 X 30MM (0.20 X 1.79 X 1.18IN)
1 POLE
GRAY
VOLTAGE RATING UR - 300V AC/DC
CSA - 300V AC/DC
IEC - 250V AC/DC
MAXIMUM CURRENT RATI

ALLEN BRADLEY • RKD3465641

1492-J70
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH
20.5 X 75 X 78.8MM (0.807 X 2.95 X 3.01 IN)
1 POLE
GRAY
PKG. QTY. OF 10
VOLTAGE RATING UR 600V AC/DC
CSA 600V AC/DC
IEC 1000V AC/DC
ATEX 690V AC/DC
MAXIMUM CURRENT RATING UR 175A
CSA 205

ALLEN BRADLEY • RKD3465639

1492-J6-Y
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH
8.1 X 60 X 39.5MM (0.319 X 2.36 X 1.56 IN)
1 POLE
YELLOW0
VOLTAGE RATING UR - 600V AC/DC
CSA - 600V AC/DC
IEC - 800V AC/DC
ATEX 550V AC/DC
MAXIMUM CURRENT RATING UR - 50A
CSA - 50A

ALLEN BRADLEY • RKD3465620

1492-J2Q
TERMINAL BLOCK
SCREW CONNECTION
SPECIALITY FEED THROUGH
2 CONNECTION POINTS ON EACH SIDE
1 POLE
GRAY
300V AC/DC

ALLEN BRADLEY • RKD3465637

1492-J6-OR
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH
8.1 X 60 X 39.5MM (0.319 X 2.36 X 1.56 IN)
1 POLE
ORANGE0
VOLTAGE RATING UR - 600V AC/DC
CSA - 600V AC/DC
IEC - 800V AC/DC
ATEX 550V AC/DC
MAXIMUM CURRENT RATING UR - 50A
CSA - 50A

ALLEN BRADLEY • RKD3465630

1492-J4-Y
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH
6.1 X 60 X39.5 MM
1 POLE
YELLOW
600 VAC/DC
35 AMPS

ALLEN BRADLEY • RKD3465632

1492-J50-G
DISCONTINUED BY MANUFACTURER
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH
18.5 X 73.4 X 63.3MM (0.728 X 2.89 X 2.49 IN)
1 POLE
YELLOW
1000V AC/DC
CSA - 600V AC/DC
IEC - 1000V AC/DC
ATEX 690V AC/DC
MAXIMUM CURRENT RATING UR - 150A
CSA

ALLEN BRADLEY • RKD3465624

1492-J3-BR
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH
5.1 X 60 X 39.5 MM (0.20 X 2.36 X 1.56 IN)
1 POLE
BROWN
600 V AC/DC UR
600 V AC/DC CSA
800 V AC/DC IEC
550 V AC/DC ATEX
25 AMP MAXIMUM CURRET UR
20 AMP CSA
